BendPak Clearfloor 10AP - Introduction and Specifications; Models Overview

10AP Series Two-Post Lifts 4 P/N 5900265 — Rev. A6 — December 2022
Table of Contents
Int
roduction 4 Maintenance 69
S
hipping Information 5 Troubleshooting 71
Safety Considerations 5 Wiring Diagrams 74
C
omponents 8 Labels 75
S
pecifications 9 Parts Drawings 78
Installation Checklist 11 ALI Store 94
Installation 12 Maintenance Log 95
O
peration 61
Introduction
This manual describes the four BendPak Two-Post Lift models:
• 10AP. A Two-Post Lift with overall height of 145
in. / 3,683 mm that raises Vehicles up to 10,000
pounds (4,536 kg).
• 10AP-168. A taller version of the 10AP with overall height of 168 in. / 4,267 mm, designed to
accommodate taller Vehicles.
• 10APX. A Two-Post Lift with overall height of 157 in. / 3,988 mm that raises Vehicles up to
10,000 pounds (4,536 kg).
• 10APX-181. A taller version of the 10APX with overall height of 181 in. / 4,597 mm, designed t
o
acco
mmodate taller Vehicles.
All models have Overhead Assemblies and clear floors. All models may be adjusted to a narrow
92-inch (2,337 mm) or a wide 102-inch (2,591 mm) drive-through dimension.
⚠ DANGER Be very careful when installing, operating, maintaining, or repairing this equipment;
failure to do so could result in property damage, product damage, injury, or (in very
rare cases) death. Make sure only authorized personnel operate this equipment. All
repairs must be performed by an authorized technician. Do not make modifications
to the unit; this voids the warranty and increases the chances of injury or property
damage. Make sure to read and follow the instructions on the labels on the unit.
More information about the full line of BendPak products is available at bendpak.com.
This manual is mandatory reading for all users of 10AP Series Two-Post Lifts, including
anyone who installs, operates, maintains, or repairs them.
Keep this manual on or near the equipment
at all times.
Technical support and service is available from your dealer, on the Web at bendpak.com/support,
by email at support@bendpak.com, or by phone at (800) 253-2363, extension 196. You may
also contact BendPak for parts replacement information (please have the model and serial number of
your unit available) at (800) 253-2363, extension 191.
