DIMENSIONS ARE IN MM
☺
1
2
3
4
ITEM
NO
PART
NUMBER
DESCRIPTION
QTY
REV
1 5600997
XPR-9/10 LOW PROFILE TRIPLE TELESCOPING ARM
WELDMENT
1
K
2 5545341
WASHER M10 x Ø20 FLAT
3
-
3 5545200
WASHER M10 x Ø18 SL
3
-
4 5530302
HHB M10 x 1.5 x 40 FULLY THREAD
3
-
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
J
J-001
UPDATED BOM REVISION AND NEXT
ASSEBMBLIES
UPDATED NEXT ASSEMBLY
05/01/2018
05/14/2018
CA
TM
00943
00946
K
UPDATED BOM REVISION
05/30/2018
TM
00953
L
UPDATED BOM REVISION AND NEXT ASSEMBLY
02/19/2020
TM
01107
NEXT ASSEMBLY
5260193
5260239
5260572
5260573
5260574
5260575
5260611
5260636
WHERE USED
XPR-9SBT
XPR-9TF
XPR-10XLS
XPR-10XLS-181
XPR-10S
XPR-10S-168
XPR-10TS
XPR-10TS-168
SHEET 1 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
L
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
JM
5215287
XPR-9/10 LOW PROFILE
TRIPLE TELESCOPING ARM
ASSEMBLY
06/23/2015
DO NOT SCALE DRAWING
1:5
SCALE:
THIRD ANGLE PROJECTION
OR
04/17/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION
1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
2.
ASSEMBLE ITEMS AS SHOWN
