8077
5
4
2
1
WHERE USED
10APX
XPR-10XLS
XPR-10XLS-LP
XPR-10AXLS
XPR-10AXLS-LP
ITEM NO
PART NUMBER
DESCRIPTION
QTY
REV
1 5595682
CABLE SAFETY Ø2.4mm
8117mm*
-
2 5580210
Ø2.4mm OVAL CABLE CRIMP
1
-
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
A
PRODUCTION RELEASE, DERIVED FROM 5595047
11/22/2017
TM
00900
B
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
05/14/2018
TM
00946
NEXT ASSEMBLY
5250083
5250203
5250312
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
TM
5595100
XPR-10XLS/AXLS Ø2.4
x 8077 SAFETY CABLE
11/22/2017
DO NOT SCALE DRAWING
1:1
SCALE:
THIRD ANGLE PROJECTION
CA
05/24/2018
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE
SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED
.
ASSEMBLE ITEMS AS SHOWN
1.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM
2.
ITEM 1 QTY FOR REFERENCE ONLY
3.
INNER EYE LOOP DIAMETER OF Ø15mm
4.
