9.1 Description of the operating and display unit
There are indicators and a button on the outside of the outdoor housing.
Yellow
Green
Red
Button
Figure 9-1: External operation and signalling
9.1.1 Operating unit in the charger cabinet (only for maintenance)
Electrically skilled person
The following operating and display unit with a charge condition traffic light and a start /
stop button can be found on the front of the charger inside the outdoor charger.
Figure 9-2: Charge condition traffic light and stop button
