9.1.2 Meaning of the charge condition indicator
Colour
Condition /
symbol
Phase / meaning
red
permanent
Charging aborted by a fault
Fault
yellow
permanent
No active charging
Check condition of charger
flashes
No active charging
Check machine conditions in
order to start
green
permanent
End of charging procedure
(no error)
Charging procedure complete,
battery fully charged
flashes
Main charging phase
Charging in progress
Battery not completely charged
off
permanent
Charging interrupted
No active charging
Removed cable
permanent
Charging interrupted
Charging procedure has
stopped
Stop button has been pressed
(Transitional status)
Figure 9-3: Meaning of the charge condition indicator
9.1.3 Function of the button
F
i
g
u
r
e
9-4: Function of the button
Symbol
Meaning
Colour
Explanation
On/Off
light grey
Press once to interrupt charging procedure
