Parts of the display and their functions16
VGA IN Receives analog RGB signals from an external device (such as a
computer).
AUDIO IN
(AUDIO1)
Receives audio signals from an external device (such as a
computer).
AUDIO IN
(AUDIO2)
Receives audio signals from an external device (such as a VCR or
DVD player).
AUDIO OUT (R/L) Outputs audio signals to an external device.
IR-IN/IR-OUT • IR-IN: For use with an IR Extender - to ensure better response
from the remote control.
• IR-OUT: Outputs the IR signal from the IR-IN input to another
display.
SPEAKERS (R/L) Outputs audio signals to external speakers.
AC SWITCH ON/
OFF
Turns on or off the main power.
AC IN Connects to a power outlet via the supplied power cord.
AC OUT Relays the AC power from the AC IN jack to another display.
