5
®®
Section 1 - Introduction
This Manual is designed for anyone using a Control panel from the KYO range.
Most of the features described in this Manual are included on all KYO Control
panels (refer to Table 1.1). However, some features are included on certain
models only, in such cases, the Control panel will be specified.
8 Programmable Input Zones (4 for KYO 4 M and KYO 4 P)
Expandable to 32 Input Zones via optional M-IN/6 Input Expanders (for
KYO 32 series Control panels)
1 Balanced 24h Tamper Zone
1 Programmable Alarm Output: 1A relay (3A on ‘G’ models)
General Features
SECTION 1 - INTRODUCTION
Control Panel
Certification Formalities
The KYO-Unit series can be purchased as out-of-the-box Control pan-
els, or as separate package components. Bentel Security S.r.l declares
that KYO-Unit separate package components comply with the essen-
tial requirements and other relevant provisions of Directive R&TTE
1999/5/CE — only when they are assembled by a security professional,
and are used as part of one of the Control panels provided for in
Section 3, and indicated in Table 1.1. in this Manual. Bentel Secu-
rity S.r.l. declares that CE Certification is not applicable when KYO
separate package components are improperly assembled or used.
Table 1.1 - Version
Version
Component
PCB Box Transf. TRF
Power Supply
BAQ15T12
Power Supply
BAQ35T12
KYO 4 M K4 BO X-M
KYO 8 M K8 BO X-M
KYO 8W M K8W BO X-M
KYO 32 M K32 BO X-M
KYO 4 P K4 BO X-P
KYO 8 P K8 BO X-P
KYO 8W P K8W BO X-P
KYO 32 P K32 BO X-P
KYO 8G P-SW1 K8G BO X-P
KYO 8GWP-SW1 K8G W BO X-P
KYO 32G P-SW 1 K32G BO X-P
KYO 8G P-SW2 K8 G BO X-P
KYO 8GW P-SW2 K8G W BO X-P
KYO 32G P-SW 2 K32G BO X-P
KYO 8G L-SW 1 K8 G BO X-L
KYO 8GW L-SW1 K8G W BO X-L
KYO 32G L-SW 1 K3 2G BO X-L
KYO 8G L-SW 2 K8G BO X-L
KYO 8GW L-SW2 K8 G W BO X-L
KYO 32G L-SW 2 K32G BO X-L
