Section 1 - Introduction
The Control panel is made up of a Control Unit, Digital Communicator and
Modem. It can be controlled from remote Keypads and/or Digital Key/Card
Readers.
The Digital Communicator can call up to 8 Telephone numbers for Teleservice
and communication to Central Stations. You can program the system to report
events using any one of the supported formats.
The NC2/VOX Voice board (accessory item) will allow the Communicator to
send 8 Voice messages to up to 8 Telephone numbers. The NC2/VOX Voice
board also provides the Talk/Listen-in feature.
The B-MOD Modem and Management software will allow you to program,
control and Teleservice (provide remote maintenance) from a remote computer.
The B-MOD/Rx Modem and the WinBCS software will allow you to program,
control, Teleservice and Monitor the system from a remote computer.
All Events, Alarms and Troubles, complete with Customer and Event details will
be logged on the Event Logger.
The User can access the system over the phone, in order to:
 Arm/Disarm the system
 Turn ON/OFF Reserved Outputs
 Activate Talk/Listen-in sessions (NC2/VOX required)
This Control panel can be programmed:
a) on-site, using an LCD or LED Keypad (accessory item);
b) on-site, using an RS232 Computer link;
c) from remote computer, using a modem and downloading software.
About the System
The Control panel
The Digital
Communicator
Voice Messages
using NC2/VOX
Teleservice
Telemonitoring
Programming the
system
Table 1.2 - Functional differences between Models
Model
Wireless
Management
Features
Partition Input (Zone) O.C. Output
KYO 4 M


 KYO 4 P No 4 4 3 x 150 mA
KYO 8 M


 KYO 8 P No 4 8 3 x 150 mA
KYO 8W M


 KYO 8W P Yes 4 8 3 x 150 mA
KYO 32 M


 KYO 32 P Yes 8
8
Expandable to 32*
3 x 150 mA
Expandable to 14 **
KYO 8G Series No 4 8 5 x 500 mA
KYO 8GW Series Yes 4 8 5 x 500 mA
KYO 32G Series Yes 8
8
Expandable to 32*
5 x 500 mA
Expandable to 16 **
**
The
M-IN/6 Expander Module manages 6 Inputs
**
The M-OUT/6 Expander Module manages 6 OC Outputs — 150 mA (6 x 150 mA)
Control panel Versions
Accessing the system
using a remote
Touch-tone Telephone
