Bentone B 2 KA - Description

11Bentone
2.10 Description
1
2
3
4
5
6
7
8
9
10
14
13
12
11
2.10.1 Components
1. Brake plate
2. Preheater
3. Electric contact X1,X2 (see
wiring diagram)
4. Air damper
5. Electrodes
6. Fan housing
7. Adjustment of nozzle assembly
8. Frame
9. Control box
10. Blast tube
11. Oil pump
12. Ignition transformer
13. Motor
14. Air adjustment
