Bentone B 2 KA - Brake Plate, Air Flow, and Working Field

8
Bentone
!
*NB It is important that
the spark does not strike
against the brake plate or
nozzle
2.4 Setting of brake plate and air flow
2.5 Working field B 2 KS,KSV
3,9-10,5 kg/h
46-125 kW
Type Motor Complete
burner
Sound
B 2 KS,KSV
110W 1,0A 230V
50Hz 6,3µF
230V 1,8A
50Hz
70
dBA ± 0,5
dBA
Max operating current, see data plate
2.5.1 Electric Specification
Burner correspond to IP 20
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
40,0 60,0 80,0 100,0 120,0 140,0
mbar
kW
2,3-3,1
10,0-11,0
0,5-1,5
ø76
ø73
ø24
