Bentone B 2 KA - Technical Data; Dimensions B 2; Dimensions, Flanges; Burner Installation

7 Bentone
165 205 53
2. Technical data
The burner is intended for:
• Light oil, B10 heating oil/biofuel blend (as defined in DIN V51603-6)
and is used for:
• Water heating generators
• Hot air generators (these require LMO 24 255 C2E)
2.1 Dimensions B 2
* Min. recommended distance to floor.
2.2 Dimensions, flanges
Flange 1
10,5
ø89,5
130-150
21
A
C
D
E
F
G
B C D E F G *H
B 2
89 254 175,5 82 150 300 200
Length of blast
tube
Protrusion from flange,
measurement B
B 2 147 122
B 2 187 162
d
1
d
2
d
3
Combustion
device
d
1
d
2
d
3
B 2 ø 90 M8-M10 ø 125-150
2.3 Burner installation
2.3.1 Hole patten
Make sure the hole pattern on the boiler is designed for burner flange.
