Bentone B 2 KA - Working Field B 2 KA,KAV; Setting of Brake Plate and Air Flow

9 Bentone
2.6 Working field B 2 KA,KAV
2,4-9,0 kg/h
28-105 kW
-
0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
20,0 40,0 60,0 80,0 100,0 120,0
mbar
kW
Type Motor Complete
burner
Sound
B 2 KA,KAV
110W 1,0A 230V
50Hz 6,3µF
230V 1,8A
50Hz
70
dBA ± 0,5
dBA
Max operating current, see data plate
2.6.1 Electric Specification
Burner correspond to IP 20
2.7 Setting of brake plate and air flow
2,7-3,3
8,0-9,0
0,5-1,5
ø76
ø78
ø22
!
*NB It is important that
the spark does not strike
against the brake plate or
nozzle
