37 Bentone
Photocell current checks
Photocell current is measured with a direct current ammeter
(mulitimeter A) connected in series with the photocell.
9.1.3 Technical data
LOA24
Pre-ignition period: 13 s
Pre-ventilation period: 13 s
Post-ignition period: 15 s
Safety period: < 10 s
Re-connection after release: < 50 s
Reaction time flame extinction: < 1 s
Ambient temperature: –20 - +60°C
Min. current with flame: 65 µA
Max current when dark, start: 5 µA
