Bentone B30A - Working Field B 30 a; Settings for Nozzle and Air Damper; Electrical Specification en 60335-2-102

8
Bentone
2.3 Working field B 30 A
2.4 Settings for nozzle and air damper
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
60 80 100 120 140 160 180 200
mbar
kW
6.0-17.0 kg/h
72-200 kW
160302-622
Type B 30 A
Electrical data, Control power
230V, 1~, 3.09A, 50/60Hz, IP20
Electrical data, Motor
-
Max fuse rating
10A
Noise level
70dBA
Max operating current, see data plate.
2.2 Electrical specification EN 60335-2-102
0
20
40
60
80
100
0
2
4
6
8
1
0
75 100 125 150 175 200
160303-219
kW
Air settings
Nozzle assembly
Scale
1
Burner output
Air
2
<˚
1
Scale nozzle assembly and air damper without damper motor.
2
Settings air damper with damper motor.
