Bentone B40 MF - Page 15

15
Bentone B40 MF/B45-2 MF
General
41
16
28
29 30 31
39
38
40
37
3536
33 34
32
21. Fan wheel
22. Measuring nipple, fan pressure
23. Burner fl ange
24. Connecting pipe, valve block return
25. Damper motor
26. Connecting pipe, preheater valve block
27. Connecting pipe, pump preheater
28. Ignition electrodes
29. Spring pressure piston
30. Preheater
31. Valve seat
32. Front nozzle holder
33. Relay box
34. 7-pole Europlug (feed)
35. 5-pole Euro plug (feed preheater)
36. 4-pole Euro plug (control signal preheater)
37. Capacitor
38. Motor
39. Air intake
40. Ignition transformer
41. Air damper
