24
Bentone B40 MF/B45-2 MF
For installers
4. BASIC SETTINGS
4.1 Examples of basic setting B40 MF
Burner output 200 kW
Estimated nozzle output 200 kW/10 kWh/kg*= 20 kg/h
Nozzle selection in accordance with the table. (See technical data) Nozzle
selection is based on the selected pump pressure and the desired effect.
According to the nozzle table, this provides the following nozzle.
Selected pump
pressure
25 bar
Nozzle 3.50 gph
Power in 20.61 kg/h => 20.61 kg/h x 10 kWh/kg* = 206 kW
* Taken from the fuel in accordance with standard DIN 51605:2010-10
Effects and nozzle selection from example
Nozzle assembly 14
Damper 7
Basic settings should only be seen as setting values to get burner to start
and establish a flame. Once the burner has started and established a flame,
it will be necessary to adjust the settings so that they are adapted to the
installation in question and the fuel used at the time.
Basic settings
The setting value for 200 kW in accordance with basic setting tables. For the
correct procedure when implementing settings, see 4.7 Nozzle assembly
control, brake plate B40 MF and 4.8 Air setting B40 MF (See technical data )
