Bentone B40 MF - Dimensions B45-2; Setting of Ignition Electrodes and Brake Plate

9
Bentone B40 MF/B45-2 MF
General
B45-2 MF Insertion length,
burner tube
Burner tube,
Dimension B
Burner tube,
Dimension C
Burner tube,
Dimension D
Standard 1 250 160 220 134
1.2.1 Burner output
9.0
-
55.0 kg/h
90
-
550 kW
* Used lower calorifi c value of
10.00 kWh/kg for rapeseed
oil in accordance with DIN
51605:2010-10
!
*NB It is important that
the spark does not strike
against the brake plate or
nozzle
a b c d e
B45-2 MF 2,5-3,0 2,0 6,5-7,0 2,0 6,0
-1
0
1
2
3
4
5
6
7
80 120 160 200 240 280 320 360 400 440 480 520 560
mbar
kW
Ø
D

C

B
513
248
265
347
375
585 250
a
b
c
d
1.3 Dimensions B45-2
1.4 Setting of ignition electrodes and brake plate
