Bentone B40 MF - 1 Technical Data; Dimensions B40; Setting of Ignition Electrodes and Brake Plate

8
Bentone B40 MF/B45-2 MF
General
1. TECHNICAL DATA
1.1 Dimensions B40
B40 MF Insertion length,
burner tube
Burner tube,
Dimension B
Burner tube,
Dimension C
Burner tube,
Dimension D
Standard 1 202 115 160 114
!
*NB It is important that
the spark does not strike
against the brake plate
or nozzle
* Used lower calorifi c value of
10.00 kWh/kg for rapeseed
oil in accordance with DIN
51605:2010-10
1.1.1 Burner output
6.5
-
29.5 kg/h
65
-
295 kW
a b c d e
B40 MF 2,5-3,0 2,0 6,5-7,0 2,0 5,0
mbar
-1
0
1
2
3
4
60 100 140 180 220 260 300
mbar
kW
Ø
D

C

B
451
202
202
527
262
316
362
e
c
d
1.2 Setting of ignition electrodes and brake plate
a
b
