BERGES electronic

09.07.2001 Operating manual ACM D2/S2 27

Table of Contents

Default Chapter3
- Table of Contents3
1 General Information5
2 Safety Instructions5
- General Safety Instructions5
- Intended Use5
- Transport, Storage, Installation6
- Electrical Connection6
- Operating Instructions6
- Miscellaneous7
3 Introduction8
4 Technical Data (Input Voltage 1 X 2209
5 Technical Data (Input Voltage 3 X 38010
6 Technical Data (Input Voltage 3 X 38011
7 Power-Derating in Function of the Switching Frequency12
8 Dimensional Data ACM D2/S2 0.37 Kw - 5.5 Kw13
9 Dimensional Data ACM D2 7.5 Kw - 22.0 Kw14
10 Dimensional Data ACM D2 30.0 Kw - 37.0 Kw15
11 Installation Examples16
- Example 1: ACM D2/S2 0.37 Kw - 2.2 Kw (1 X 230V)16
- Example 2: ACM D2/S2 0.75 Kw - 37.0 Kw (3 X 400V)17
12 Installation18
- Mains Power Connection18
- Motor Connection19
- Interference Suppression Measures / EMC (Electromagnetic Compatibility)19
  - General Information19
  - Installation Notes19
- Mains Back-Up Fuses20
- Ventilation20
- Control Terminals21
- Power Terminals22
13 Commissioning and Settings23
- General Information23
- Adaption to Operation23
14 Operating Functions24
- General24
- Control Panel24
- Display25
- Help - Function and Language - Select25
- Inverter Status25
- Warnings26
- Operating Error Messages26
- Hardware Error Messages27
15 Programming ACM D2/S228
- Program Structure28
- Program Level TAB130
- Program Level TAB240
- Program Level TAB345
16 Braking Chopper ACM D2/S253
- Braking Chopper 0.37 Kw - 1.1 Kw (1 X 230V)53
- Braking Chopper 0.75 Kw - 37.0 Kw (3 X 400V)53
  - Minimum Values for Braking Resistors (Accessory)53
  - Assembling the Braking Resistor53
17 Accessories54
- Programming Key54
- Telecomander RC55
- DVM - Plus Mp55
- ACM - Synchronizer55
18 Faults and Remedies56
19 Functions of ACM D2/S257
20 Notes60
