2.2 AVAILABLE VERSIONS
EUROMAG manufactures its sensors in dierent versions, each intended for use in dierent applications, as
summarized in the paragraph “1.5 Applications.”
The dierent sensor versions available are shown below.
2 . 2 . 1 Flanged sensors

MUT2200EL – Full Bore

MUT2300 – Reduced Bore
2 . 2 . 2 Wafer sensors

MUT1000EL - Wafer

MUT1100J - Wafer in plastic material
2 . 2 . 3 Insertion sensors

MUT1222

MUT2660

MUT2770
2 . 3 TYPES OF INSTALLATION OF THE SENSOR
The sensors in dierent versions can be connected to the converter in two dierent ways, namely:
Flanged Sensors Wafer Sensors Insertion Sensors
COMPACT installation: The
sensor is connected directly
to the related converter.
SEPARATE installation
[remote]: The sensor is
connected to the converter
by specific power/signal
cables.
