3 . 2 . 3 Negative pressure
Avoid vacuum conditions in the pipe. These can damage the coating of the flowmeter and move the electrodes
from their correct position.
3 . 2 . 4 Protection from direct sunlight

Protect the flowmeter if exposed to direct sunlight.
3 . 2 . 5 Operating temperatures

For normal and ecient operating of the flowmeter:
The room temperature must be limited within the range of (-25 ÷ +60) °C, (-13 ÷ +140) °F.
°C °F
Min. Max. Min. Max.
Coating in EBONITE -40 +80 -40 +176
Coating in PTFE (remote) -40 +130 -40 +266
Coating in PTFE (compact) -40 +80 -40 +176
Coating in PTFE (separate high temperature) -40 +180 -40 +356
MUT1100J 0 +80 32 +176
INSERZIONI -20 +80 -4 +176
Fig. 9 Avoid direct exposure to sunlight
Fig. 10 Environment and fluid temperature limits
