Irrigation IOM
Sensors
| 34 |
5
.
3
SEPARATION CABLES
Optional single-shielded electrode cables - C022
Optional double-shielded electrode cables - C028
C028 cables are provided with double shielding, one external, and one additional shielding of the single signal
cables of the measuring electrodes only.
C022
F
D
T
C
E
PVC outer jacket Shield
Fig. 54 Standard single-shielded electrode cables - C022
D
E
C028
T
C
F
PUR outer jacket EXTERNAL shield
Fig. 55 Optional double-shielded electrode cables - C028
