Model H79
14
Installing the Bobbin
To put the bobbin in the machine, follow these steps:
1. Slide open the bobbin cover by sliding the small black slide bar to
the right. Remove the plastic cover. If the clear plastic cover does
not ip up, slide it to the right a bit.
2. Insert the bobbin into the shuttle with the thread direction as
noted in the etching under the bobbin cover.
3. Guide the thread around the nger of the machine through the
channel toward the back, and then pull the thread toward you to
cut the thread end. The thread will be cut at the end of the channel
and be ready for use.
Operation
H79_Manual.indd 14H79_Manual.indd 14 10/6/2008 4:29:06 PM10/6/2008 4:29:06 PM
