Sewing preparations
11
Sewing preparations
The FHS raises and lowers the presser foot.
Attaching the lifter
⦁
insert into the opening; you should be able to operate the FHS with your
knee in your normal sitting position
Raising and lowering the presser foot
⦁
with your knee push lever to the right
⦁
the presser foot is raised; the feed dog is lowered simultaneously. The
thread tension is released
⦁
the feed dog is raised as soon as the first stitch is sewn
FHS (Free Hand System) (optional accessory for B 335 only)
⦁
the vertical spool pin is on the side behind the handwheel
⦁
it is an essential aid for sewing with more than one thread, i.e. double
needle work
⦁
raise the pin until it clicks into its vertical position
⦁
when using large reels, add the foam pad A for stability
Vertical Spool Pin
Your dealer can adjust the FHS if necessary.
A
