Setting up the machine
44
Changing the presser foot
Prerequisite:
• The needles are in the top position.
• The presser foot is raised.
> Press the release button on the rear side of the presser foot shaft.
– The presser foot is released.
> Lift the presser foot spring slightly and remove the presser foot.
> Lift the presser foot spring slightly and place the new presser foot beneath the shaft groove so that the
shaft groove lies exactly above the presser foot pin.
> Lower the presser foot shaft carefully until the shaft groove engages with the presser foot pin.
> Raise the presser foot.
3.5 Needle area
Needle holder
The needle holder can hold five needles. The machine is designed for needles of the ELx705 system. Needle
sizes between 70 − 90 are to be used for this machine. (see page63)
