82.526 - HERMES 3
CONTENTS
1. General ______________________________________________________________ 5
1.1. Technical characteristics 5
1.2. Overall dimensions 6
1.3. Weights table 6
1.4. Information plate 7
1.5. Noise measurements 7
1.6. Position of safety stickers 8
2. Presentation of the equipment _____________________________________ 9
2.1. Step 9
2.2. Direct reading oat gauge 9
2.3. Tape gauge (Option) 10
2.4. Boom height 10
2.5. Rinsingtank 10
2.6. Hand washtank 11
2.7. Main tank drain 11
2.8. Agitation 11
2.9. Rinsing balls 11
3. Starting-up the sprayer ___________________________________________ 12
3.1. Adapting the transmission shaft 12
3.2. Hitching the equipment to the tractor 12
3.3. Unhitching the sprayer 12
3.4. Rinsingbefore using for the rst time 13
3.5. Recommendations for use 13
4. Main sprayer functions with Gama 101 or Gama 130 pump _____ 14
4.1. Adjusting the valves 14
4.2. Filling the main tank 14
4.3. Induction hopper 15
4.4. Spraying functions Positions 1-10 16
4.5. Complete rinsing functions: Positions 11-15 17
4.6. Adjusting calibrated returns 17
