82.526 - HERMES 5
1. GENERAL
1.1 TECHNICAL SPECIFICATIONS
HERMES Mounted Sprayer, regulation AUTOREGLEUR
Structure
Chassis
Single-piece chassis protected by UHR polyester paint
Stainless steel nuts and bolts
Retractable step for access to the manhole.
Boom lifting on mast with suspension on nitrogen ball
Hitching
3-point hitch
Fixed standing feet (with optional handling casters)
Tanks
Main tank
High density polyethylene tank with large lling hole
Capacity: 800, 1000 or 1200 litres.
Rinsing tank 120-litre polyethylene rinsing tank
Handwash tank 18-litre polyethylene handwash tank.
Gauges
Direct read oat gauge (main tank and rinsing tank).
Tape gauge (optional on main tank).
Regulation
Pump
Gama 101 3 piston volumetric pump (20 bar, 105 litres/minute).
Optional Gama 130 pump (20 bar, 130 litres/minute).
Regulation Self-adjuster Autoregleur, E.C.Control or E.C.Tronic.
Controls
Transmission Universal joint transmission
Electric valves
Remote spraying control by electric check valves (ECV) with main cut-off on the
control box in the cab.
Electronic box Autoregleur Box, E.C.Control or E.C.Tronic.
Use
BERLOGIC panel (manually controlled valve block). It contains all the equipment's
functions to make use easier.
Standards
Road signals Complies with trafc regulations.
Approvals Environmental compliance
Functions
Filling
Filling via the manhole or via the hydro-ller.
Connection via 2" quick connector.
6m lling pipe with strainer.
25-litre retractable induction hopper with cans and circuit rinsing system.
Filtration
On lling (main tank):
- Strainer, 8/10 mesh.
On suction (main tank and rinsing tank):
- Filter, 6/10 mesh.
On delivery:
- Filter, 4/10 mesh.
Agitation Agitation by Hydromax with intensity adjustment on BERLOGIC panel.
Rinsing
Cleaning the main tank with rinsing balls (Lav'ton).
Rinsing the boom without return to the main tank.
