ENGLISH Gold/Plus/Easy refrigerated cabinets
60
Ed. 12/2020
2.8 Reversing the door
The default opening direction of the appliance is to the “right” (opening from right to left). If it is necessary to reverse
the opening direction of the door, proceed as follows:
– take the upper right hinge (1);
– make sure there are no food products inside the appli-
ance. Empty it, if necessary;
–
disconnect the appliance from the electrical power
supply;
STANDARD
1
Fig. 9
– place a spacer (2) under the door to support it;
– remove the screws (3) from the lower bracket (4);
m
BE CAREFUL
Once the screws have been removed, the bracket will turn inwards: assist it and leave it hanging free from
the door.
– support the door, remove the support spacer and allow it to drop a few centimetres until it slides off the pin of
the upper hinge (5);
– rest the long side of the door on the floor (6), with the hinges facing upwards;
2
6
3
4
5
Fig. 10
