Programme selector PCD
16 Issued 2006-12-21 1003090-EI-2.0
7.3.1 The different operating modes
Closed (locked) 01
The door rotates to its closed position. If an electromechanical lock is fitted, the
lock is activated. The door can be opened with the key impulse switch, see “The
ON/OFF switch” on page 15. In this mode 01, the door will not run, even if the
ON/OFF switch is set to ON.
Automatic operation, start from open position 02
As soon as the outside or inside activation units detect approaching traffic, the
door starts rotating.
Continuous rotation 06
The door rotates at a low speed. As soon as the outside or inside activation units
detect approaching traffic, the door accelerates to normal speed. The door returns
to low speed when there is no traffic.
ILL-00180
Key impulse switch
ILL-00189
ILL-00190
