Programme selector PCD
22 Issued 2006-12-21 1003090-EI-2.0
7.9 Door operation
Press the number key relating to the number in front of the desired operation
mode to select.
Press Enter to confirm changes.
Press ESC to return to main menu.
7.9.1 Other information on screen (EI)
Manually locked
The ON/OFF switch is in OFF position. It is not possible to give an impulse from
the terminal when the ON/OFF switch is in OFF position.
Service request
The door has been running for 300.000 revolutions.
Call fore service.
Real time
Real time operation is active.
Type R to toggle between real time operations ON/OFF.
Error/Status Display: ON
Operating Mode: 2 Real Time Mode 1
Door Speed (RPM/10): 0
Revolution Counter: 35552
Date & Time: Monday 2005-06-13 13:07:16
Operating modes:
1: Lock Door
2: Auto Open = Start from open position
6: Continuous Rotation
7: Manual Operation
Press function key: C: Error Clear
I: Key Impulse
R: Real Time Operation ON/OFF
