MAINTENANCE AND CHECKS

SPSP

ARK PLARK PL

ARK PL

UGUG

Keeping the spark plug in good condition reduce fuel consumption and increase

engine performance.

To perform the check, simply slide off the electrical connection tube and unscrew

the spark plug.

Examine the distance between the electrodes with a feeler. This distance should be

from 0.5 to 0.6 mm. If it is not, it may be corrected by bending the earth electrode.

Check as weII that there are no cracks in the insulation or corroded electrodes. If

so, replace immediately.

Observe the chart on page 66 when performing the check.Observe the chart on page 66 when performing the check.

Observe the chart on page 66 when performing the check.

When replacing the spark plug, screw it in by hand until it stops, then tight with a

wrench.

Note:Note:

Note:

•The use of Iow-quality oil will cause an increase in carbon deposits. We therefore

advise the use of BARDHAL KXT oil.

•Always use NGK BR7ES spark plugs.

GENERAGENERA

GENERA

OR (IGNITION GENERAOR (IGNITION GENERA

OR (IGNITION GENERA

OR CHECK)OR CHECK)

OR CHECK)

Check must be performed with a component temperature of about 20°C.

Check can also be performed with the generator mounted on the motor bike or on

the engine.

Unplug the black 12 pins connector between the generator and CDI.

Verify with a multimeter that the resistance values among the below indicated pins

are in the prescribed range:

• black- white (Pick-Up) 320 ohm ± 15%

• red-blue (capacitor charge) 300 ohm ± 15 %

• yellow-brown (services supply) 0,45 ohm ± 20%
