MAINTENANCE AND CHECKS
GB
3
FRONT BRAKEFRONT BRAKE
FRONT BRAKEFRONT BRAKE
FRONT BRAKE
CheckCheck
CheckCheck
Check
To check the front brake wear, simply ob-
serve the caliper from the front, where it is
possible to see the ends of the two pads.
These pads should have at Ieast a 2 mm
Iayer of Iining. If this layer is thinner than 2
mm, replace the pads immediately.
Note:Note:
Note:Note:
Note:
Observe the times given on the chart on
pag. 66 when performing the check.
ReplacementReplacement
ReplacementReplacement
Replacement
To replace the pads, proceed as follows:
•Disassemble the disk cover and the
caliper by unscrewing the two screws
AA
AA
A
and loosening the screw
BB
BB
B
•Take off the split pin
CC
CC
C
•Unscrew the screw
BB
BB
B
•Remove the pads
D D
D D
D and replace them
•To reassemble, proceed in the reverse or-
der. Apply medium thread-locking
(frenafiletti medio) to the screws
AA
AA
A
Note:Note:
Note:Note:
Note:
To avoid braking problems, pay particular
attention to the correct reassembly of the
split pins.
If the brake disk is removed, ap-If the brake disk is removed, ap-
If the brake disk is removed, ap-If the brake disk is removed, ap-
If the brake disk is removed, ap-
ply medium thread-lockingply medium thread-locking
ply medium thread-lockingply medium thread-locking
ply medium thread-locking
to theto the
to theto the
to the
screws when reassembling.screws when reassembling.
screws when reassembling.screws when reassembling.
screws when reassembling.
