Beta EVO 2T Instruction Manual

68
ADJUSTEMENTS
GB
4
ADJUSTMENT OF BRAKESADJUSTMENT OF BRAKES
ADJUSTMENT OF BRAKESADJUSTMENT OF BRAKES
ADJUSTMENT OF BRAKES
FF
FF
F
ront brakeront brake
ront brakeront brake
ront brake
The front brake is disk type with hydraulic
control, and therefore requires only ordi-
nary maintenance. If you want to adjust
the position of the lever, use register
AA
AA
A.
RR
RR
R
ear brakeear brake
ear brakeear brake
ear brake
The rear brake is disk type with hydraulic
control. You may adjust pedal height by
means of registers
BB
BB
B and
CC
CC
C.
A minimum of clearance is
reccommended.
ADJUSTMENT OF CLADJUSTMENT OF CL
ADJUSTMENT OF CLADJUSTMENT OF CL
ADJUSTMENT OF CL
UTUT
UTUT
UT
CHCH
CHCH
CH
Only operation that is performed on the
clutch is adjustment of the position of lever
EE
EE
E
..
..
. To do this, use register
DD
DD
D
..
..
.
Note:Note:
Note:Note:
Note:
The device you pressure plate must have a
play between 0.4 mm and 0.6 mm. There-
fore, proceed as follows when replacing
disks:
•Reassemble the clutch without the outer
cover
•Send the control rod to end of travel by
pushing the pressure plate and measure
distance
F F
F F
F
•Operate the clutch lever until the control
rod activates the pressure plate. Measure
distance
GG
GG
G and check that there is
difference of approximately 0.4-0.6mm.

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
