1
GENERAL INFORMATION
11
GB
CONTROLS
CLUTCH LEVER
The clutch lever 1 is located on the left
side of the handlebar. See the Adjustments
chapter to adjust.
STARTER
The starter lever 2 is located on the left side
of the handlebar. Turn the lever counter-
clockwise to operate.
SWITCH
The dip and service switch is located on
the left side of the handlebar and is com-
posed as follows:
3 Horn button;
4 Dip switch
( high beam ; low beam)
5 Shut-down;
6 Turn signal light switch
FRONT BRAKE LEVER AND GAS CONTROL
The front brake lever 7 and the gas throt-
tle 8 are located on the right side of the
handlebar.
7
8
1
5
2
3
6
4
