MANUAL MAINTENANCE
Version: 6.1 (05-12-2011) 49
2. Remove the aluminum grille from the inlet grille:
- Slide the grille upward.
- Tilt the grille a little up.
- Remove the aluminum grille from the grille.
3. Clean or replace the filter.
correct
wrong
Note:
n When putting the grille back:
Ensure you put it back correctly into the inlet grille.
1
1
Recessed and cassette models
1. Open the inlet grille:
- Push the two pins 1 in the grille towards one
another
: The grille will tilt down.
2. Slide the filter out of the grille.
3. Clean or replace the filter.
1
1
Long-life filter in free-hanging models
1. Remove the inlet grate from the unit:
- Lift the grate at the bottom and unhook it.
2. Loosen the screws 1.
