INSTALLATION COMFORT AIR CURTAIN
22
2.7 Connecting the unit to the power supply
2.7.1 All models
Warning:
w Do not turn on the unit from the power supply. Use
the control panel.
Warning:
w Every unit must be separately fused in accordance
with table 2-2.
Table 2-2 Fus
e values
Note:
n Multiple units may only be served by a common fuse if
their total current consumption is less than 10A.
2.7.2 Models with water heating (CA
2
W) and models
for connection to a Daikin system (CA
2
V and
CA
2
Q)
1. Ensure that an (earthed) power point is available at a
m
aximum of 1.5 m from the left side of the unit.
Warning:
w The unit must be grounded.
M
AXIMUM AMPERAGE ON
TYPE PLATE
L1, L2 OR L3
M
AXIMUM FUSE VALUE
A
<= 10A 16A
<= 15A 20A
<= 20A 25A
<= 25A 35A
<= 35A 50A
<= 50A 63A
<= 65A 80A
<= 80A 100A
<= 102A 125A
