Layouts and Sectional Drawings
Section 7: Layouts and Sectional Drawings
June 2020
Installation, Operation and Maintenance Manual
NOTE:
* Recommended spare parts
Figure 27 Assembly kit
Table 23. Parts list
Item Qty Description Material
1 4 Screw Alloy steel
2 2 Gasket * SBR + Cellulose + llers
3 1 Plug Carbon steel
4 1 Washer * Carbon steel
5 4 Screw Alloy steel
6 4 Screw Alloy steel
7 4 Washer Copper
Spring to close assembly Spring to open assembly
