REV A 5-4 122832
The vapor lines are connected to the fuel tank as shown.
They connect the fuel tank to the engine’s vapor port.
Figure 5-12, Figure 5-13 & Figure 5-14
48"/52"/60" Mowers with Kawasaki engines
A. Fuel tank B. Fuel line
Figure 5-9
48"/52"/60" Mowers with Kohler engines
A. Fuel tank B. Fuel line
Figure 5-10
A
B
B
A
B
B
36" Mowers with Kawasaki engines
A. Fuel tank B. Fuel line
Figure 5-11
48"/52"/60" Mowers with Kawasaki engines
A. Fuel tank
B. Vapor lines
C. Fuel evaporation sys-
tem filter
Figure 5-12
A
B
B
B
A
B
B
B
C
