48"/52"/60" Mowers with Kohler engines
A. Fuel tank
B. Vapor lines
C. Fuel evaporation sys-
tem filter
Figure 5-13
36" Mowers with Kawasaki engines
A. Fuel tank
B. Vapor lines
C. Fuel evaporation sys-
tem filter
Figure 5-14
A
B
B
B
C
A
B
C
B
B
