Attach the handlebars to the stem. Get the
box with the tools. In this box you will nd 4
M5 screws as well as a 3-ended allen wrench
(See image F).
Fasten the handlebars onto the bike. Make
sure that the wires are not tangled and that
the handlebars are in their correct position.
Fasten the stem screws to 9.8 newtons or
until the handlebars do not move. Be care-
ful not to strip the threads and make sure
that the center of the handlebar lines up
with the center of the frame (See image G).
To unfold your bike, stand on the LEFT side of the bike, with your left hand on the left handle
grip.
• Slide the stainless steel button on the folding lever upwards so that the lever pops
out of the frame (see image H).
• Make sure that the left pedal crank is not interfering with the bike’s front wheel
(see image I).
• Push the front wheel forward with your left hand on the left grip while simultaneously
pulling the back wheel up and backwards using your right hand on the lever (see
image J).
• Push the folding lever back down into the frame and slide the stainless steel button
down to secure the lever and lock the folding mechanism (see image K).
Unfolding your Gi Fly for the rst time
F
G
H
I
J
K
