BIGTREETECH ADXL345 V2.0

BIGTREETECH ADXL345 V2.0 User Manual
11
Assembly
Note: Avoid overtightening screws during installation to prevent damage.
Example using the Voron StealthBurner:
Method 1:
Install on the side bracket with the dual holes (matches official spacing).
Method 2:
Use screws through the PCB and rubber ring on the heater block as shown.
