Billion BiPAC 5200N User Manual

ADSL
Transmit total PDUs: This field displays the number of total PDU transmitted in the last
second.
Transmit total Error Counts: This field displays the number of total error transmitted in
the last second.
Receive total PDUs: This field displays the number of total PDU received in the last
second.
Receive total Error Counts: This field displays the number of total error received in the
last second.
WLAN
Tx Frames Count: This field displays the number of frames transmitted in the last
second.
81

Billion BiPAC 5200N Specifications

Operating Environment

operating temperature	0 - 40 ºC
storage temperature	-20 - 70 ºC
humidity	20 - 95% non-condensing

Physical Specifications

dimensions	185mm x 123.5mm x 36mm
wireless operation rate	Up to 300Mbps
frequency range	2.4 GHz – 2.484 GHz

Power

input voltage	12V DC
input current	1A
