applications. Both applications need minimal or higher bandwidth, besides the assigned one, if
there is any available/non-used one available, you can specify which application can have higher
priority by acquiring the non-used bandwidth. Average utilization of each priority type: High (60%),
Normal (30%) and Low (10%).
High
Normal: The default is set to normal.
Low
For the sample priority assignment for different policies, it is served in a First-In-First-Out way.
DSCP Marking: Differentiated Services Code Point (DSCP), it is the rst 6 bits in the ToS byte.
DSCP Marking allows users to classify the trafc of the application to be executed according to
the DSCP value. See DSCP Mapping Table.
Note: Make sure that the router(s) in the network backbone are capable to execute and check
the DSCP throughout the QoS network.
DSCP Mapping Table
DSCP Mapping Table
(Wireless) GPON Router Standard DSCP
Disabled None
Best Effort Best Effort (000000)
Premium Express Forwarding (101110)
Gold service (L) Class 1, Gold (001010)
Gold service (M) Class 1, Silver (001100)
Gold service (H) Class 1, Bronze (001110)
Silver service (L) Class 2, Gold (010010)
Silver service (M) Class 2, Silver (010100)
Silver service (H) Class 2, Bronze (010110)
Bronze service (L) Class 3, Gold (011010)
Bronze service (M) Class 3, Silver (011100)
Bronze service (H) Class 3, Bronze (011110)
Remember clicking Apply to save your settings.
