14
8.2. Matrix Control from Room Enable
Default Setting: Yes
The Matrix Control From Room Enable option allows Matrix Control IR commands to be sent from the room as if
a source were being controlled. Turn this option off if the matrix switcher is being controlled by any other method
than in-room IR.
Note: To use Matrix Control From Room, it is recommended to program a universal remote control with discrete
commands for matrix control to keep in each zone, rather than using the included IR remote or commands learned
from it. Go to the Support tab of the B-120-HDMATRIX-4x4 product page at www.SnapAV.com to see and
download the available IR codes and drivers for IR remote programming.
8.3. Front Panel Power Button Active
Default Setting: Yes
The front panel power button can be disabled if desired. Disable the button when the matrix switcher is
programmed to be on at all times or in jobs where turning off the matrix from the switcher can cause issues with
control.
9. FIRMWARE UPDATE
Binary™ may occasionally release new rmware for theB-120-HDMATRIX-4x4 to address new standards and
technology. It will never be necessary to perform an update to an existing, correctly functioning system, but during
installation or service, it is recommended to check the installed version to be sure it is the newest available.
For full update instructions, see the section titled Firmware Update in the Conguration Utility Manual. New
rmware, the Conguration Utility, and the Conguration Utility Manual are available for download on the
Support tab of the B-120-HDMATRIX-4x4 product page at www.SnapAV.com.
10. OPERATION AND CONTROL
During setup and testing, use the included IR remote to control the matrix switcher. After setup is complete, a
control method should have been setup and programmed as described in Section 6.7. Matrix Control Connections for
regular operation.
