Binary 120 Series User Manual

4
1. PRODUCT OVERVIEW
Welcome to Binary™. This product is engineered to provide years of exceptional reliability. We appreciate your
business, and we stand committed to providing our customers with the highest degree of quality and service in
the industry.
The B-120-HDMATRIX-4x4 is a state-of-the-art HDMI matrix switcher with HDMI outputs. It provides true matrix
routing for HDMI signals. With features such as HDMI 3D support, sophisticated EDID handling, and IR, RS-232
and Ethernet control, this product is ideal for residential and commercial media distribution systems.
Note: This manual covers installation and setup of the B-120-HDMATRIX-4x4 for most applications. Some
features must be congured using the Conguration Utility software. Go to the product page for the B-120-
HDMATRIX-4x4 at www.SnapAV.com and click on the Support tab to download the Conguration Utility and
manual.
2. FEATURES
• 4 HDMI inputs by 4 HDMI outputs
• Supports video resolutions up to1080p/60 36bit color
• Supports all HDMI audio formats
• Supports all HDMI 3D formats
• Sophisticated EDID handling including embedded, learned, and auto modes
• HDMI or DVI with adapter (not included)
• IR Control from integrated receiver or 3.5mm input
• Home Control via IR, RS-232 and Ethernet
• PC Setup and conguration using dedicated software
• HDCP 2.0 compliant
• CEC Passthrough
3. PACKAGE CONTENTS
• 1x B-120-HDMATRIX-4x4
• 2x rack ears for mounting
• 8x screws
• 1x IR remote control
• 1x Power supply 12VDC, 5A
• 1x Installation Manual
• 1x CD-ROM

Binary 120 Series Specifications

General

HDCP Version	2.2
Resolution Support	Up to 4K@60Hz (4:4:4)
Input Channels	12
Output Channels	12
Signal Type	HDMI
Power Supply	100-240VAC, 50/60Hz
Weight	3.5kg
HDMI Version	2.0
Audio Support	Dolby Digital
Control	IR
Control Interface	RS-232, IR
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
