13. SPECIFICATIONS
TECHNICAL
HDMI Compliance HDMI 3D
HDCP Compliance Yes
Video Bandwidth 6.75Gbps
Input TMDS Signal 1.2 Volts (peak-to-peak)
Input DDC Signal 5 Volts (peak-to-peak, TTL)
ESD Protection (1) Human body model — ±15kV (air-gap discharge) & ±8kV (contact discharge) (2)
Core chipset — ±8kV
IR Signal (Bidirectional) Carrier frequency: 20-60kHz
CONNECTIONS
HDMI 8xHDMI Type A (19-pin female)
IR (In) 1x3.5mm Mono
RS-232 DB9
Power Polarized
Ethernet 1xRJ45
MECHANICAL
Housing Metal enclosure
Dimensions (W x H x D) 17.32" x 1.73" x 6.38" (without ears)
Weight 5.1 lbs.
Power Supply 12V 5A
Matrix Power
Consumption
20W
Operation Temperature 32~104°F
Storage Temperature -4~140°F
Relative Humidity 20~90% RH (no condensation)
Certications and
Compliance
Product: CE, FCC, Rohs
Power Supply: CE, FCC, Rohs, UL

Binary 120 Series Specifications

General

HDCP Version	2.2
Resolution Support	Up to 4K@60Hz (4:4:4)
Input Channels	12
Output Channels	12
Signal Type	HDMI
Power Supply	100-240VAC, 50/60Hz
Weight	3.5kg
HDMI Version	2.0
Audio Support	Dolby Digital
Control	IR
Control Interface	RS-232, IR
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
