Binary 120 Series User Manual

16
10.1.2. Turn Off (Mute) Outputs
Mute one Output Example: Output=1 Display Readout (Example)
1. Press OUTPUT --
2. Press Number Key (1-4) to select Output 1-
3. Press OUTPUT OFF 10
4. Press ENTER 10
Mute All Outputs Display Readout (Example)
1. Press OUTPUT --
2. Press ALL to select All Outputs A-
3. Press OUTPUT OFF A0
4. Press ENTER 40
10.1.3. Display Output Status
Display Readout (Example)
Example Output=3,
Input=4
Example Output=3
Muted
1. Press STATUS -- --
2. Press OUTPUT -- --
3. Press Number Key (1-4) to select one Output 3- 3-
4. Press ENTER 34 30
10.1.4. Resetting to Factory Defaults
This procedure resets the B-120-HD-MATRIX to factory defaults:
• EDIDs - 1080p Stereo (embedded EDID 2)
• I/O - All Outputs set to Input 1
• 1CAT EDIDs cleared, DHCP - Enabled.
Reset Factory Defaults Display Readout (Example)
1. Press DEFAULT E-
2. Press DEFAULT --
3. Press DEFAULT --
4. Press DEFAULT DD
5. Press ENTER D-
Note: Resetting factory defaults can take up to 2 minutes to complete. Wait until the screen displays an output and
input selection of 1.1 before attempting further setup or use.

Binary 120 Series Specifications

General

HDCP Version	2.2
Resolution Support	Up to 4K@60Hz (4:4:4)
Input Channels	12
Output Channels	12
Signal Type	HDMI
Power Supply	100-240VAC, 50/60Hz
Weight	3.5kg
HDMI Version	2.0
Audio Support	Dolby Digital
Control	IR
Control Interface	RS-232, IR
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
