BF (E1) 05/2016 page 7/58
1.4 Type plate
The type plate is located on the chamber front behind the door, bottom left-hand.
Figure 1: Type plate (example: BF 115 regular chamber)
Figure 2: Type plate (example: BF 115 optional chamber)
Indications of the type plate (example)
Information
BINDER
Manufacturer: BINDER GmbH
BF 115
Model designation
Incubator
Device name
Serial No.
00-00000
Serial no. of the chamber
Built
2015
Year of construction
Nominal temperature 100 °C
212°F
Nominal temperature
IP protection
20
IP type of protection acc. to EN 60529
Temp. safety device
DIN 12880
Temperature safety device acc. to standard DIN 12880
Class
3.1
Class of temperature safety device
Art. No.
9010-0237
Art. no. of the chamber
Project No.
---
Optional: Special application acc. to project no.
0,40 kW
Nominal power
1,8 A
Nominal current
230 V / 50 Hz
Nominal voltage ± 10%
at the indicated power frequency
230 V / 60 Hz
1 N ~
Current type
With option internal socket:
Nominal power: 0,90 kW
With option internal socket: increased total nominal power
Nominal temp.
100 °C
0,40 kW / 1,8 A
With option internal socket:
212 °F
230 V / 50 Hz
Nominal power: 0,90 kW
IP protection
20
230 V / 60 Hz
Safety device
DIN 12880
1 N ~
Class
3.1
Art. No.
9010-0237
Project No.
Built
2016
Incubator
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
BF 115
E1
Serial No. 00-00000
Made in Germany
Nominal temp.
100 °C
0,40 kW / 1,8 A
212 °F
230 V / 50 Hz
IP protection
20
230 V / 60 Hz
Safety device
DIN 12880
1 N ~
Class
3.1
Art. No.
9010-0237
Project No.
Built
2016
Incubator
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
BF 115
E1
Serial No. 00-00000
Made in Germany
