Press key
Display 1 shows
0000
Display 2 shows PrgSelec: 2Prg10S
(1 program with max. 20 sections or
2 programs with max. 10 sections each?)
(actual setting: 2Prg10S)
Select
between “2Prg10S” and “1Prg20S”
using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Prg.Time: 99:59
(max. section length 99:59 or 999:59?)
(actual setting: 99:59)
Select between 99:59 in hh:mm or 999:59 in
hhh:mm using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Setp.sim Ramp
(ramp or step?)
(actual setting: ramp)
Select between Ramp and Step using arrow
keys
Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Tol.band 0
(Tolerance limits in °C)
(actual setting: 0)
Set value in °C using arrow keys Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Prog.Clk Inactive
(Week program timer active or inactive?
(actual setting: Inactive)
Select between “Active” and “Inactive” using
arrow keys
Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows 12h/24h 24h
(Display mode 12 hours or 24 hours?
(actual setting: 24h)
Select between 12 hours and 24 hours us-
ing arrow keys
Setting is shown in display 2.
