Binder KMF-720 - Type Plate

KMF (E5.2) 06/2014 page 12/99
1.4 Type plate
The type plate sticks to the left side of the unit, bottom right-hand.
Figure 3: Type plate (example of KMF 240 regular unit)
Indications of the type plate (example)
Information
BINDER
Manufacturer: BINDER GmbH
KMF 240
Model designation
Constant climate chamber
Device name
Built
2014
Serial no. of the unit
Serial No.
00-00000
Year of construction
Nominal temperature
100 °C / 212 °F
Nominal temperature
Enclosure protection
IP 20
IP type of protection acc. to EN 60529
Temp. safety device
DIN 12880
Temperature safety device acc. to standard DIN 12880
Class
3.1
Class of temperature safety device
Art. No.
9020-0145
Art. no. of the unit
Project No.
---
Optional: Special application acc. to project no.
2,10 kW
Nominal power
200-240 V 1 N ~
Nominal voltage +/-10%, phase indication
9,5 A
Nominal current
50/60 Hz
Power frequency
Max. operating pressure 15 bar Max operating pressure in the refrigerating system
(15 bar / 218 PSI)
R 134A - 0,575 kg
Refrigerant type and filling weight
Contains fluorinated greenhouse gases covered by the Kyoto Protocol
Symbol on the type plate
Information
CE conformity marking
Electrical and electronic equipment manufactured / placed
on the market in the EC after 13 August 2005 and be dis-
posed of in separate collection according to the directive
2002/96/EC on waste electrical and electronic equipment
(WEEE).
The equipment is certified in the GOST R certification sys-
tem of GOSTSTANDARD Russia.
Nominal temperature
100°C
2,10 kW
MAX. OPERATING PRESSURE 15 BAR
212°F
200-240 V 1 N ~
R 134A - 0,575 KG
Enclosure protection
Temp. safety device
Class
IP 20
DIN 12880
3.1
9,5 A
50/60 Hz
Contains fluorinated greenhouse gases
covered by the Kyoto Protocol
Art. No.
9020-0145
US PATS 4585923 / 5222612 / 5309981
Project No.
5405194 / 5601143 / 5773287 / 6079403
Built
2014
Constant climate chamber
D 78532 Tuttlingen / Germany
Tel. + 49 (0) 7462/ 2005-0
Internet: www.binder-world.com
KMF 240 Serial No. 00-00000
E5.2
Made in Germany
